| Sizes in mm(inch) | 15 (1/2″)mm to 300 (12″) mm |
| Design Feature | Weir type and straight through type |
| Pressure Rating | PN 5, PN 7, PN 10, PN 16 |
| Temperature | -300C TO -1750C |
| Design Std. | BS EN 13397 (BS-5156) |
| Face to Face Dimensions | ANSI B16.10 |
| Testing Std. | BS 6755-1 / EN 12266-1 |
| Material of Construction | CI, WCB |
| Lining Material | Natural and Synthetic Rubber, Pfa |
| Special Features | Locking |
| End Connection | SCREWED : ANSI B1.20.1 BS: 21 IS: 554, Flanged Ends |
