| Sizes in mm(inch) | Pressure Rating |
|---|---|
| 50 (2″) to 750 (30″) | Class 150 & 300 |
| 50 (2′) to 600 (24′) | Class 600 |
| 15 (2′) to 400 (16′) | Class 900 |
| 15 (2′) to 300 (12′) | Class 1500 |
| Design Std. | BS EN ISO 17292 (BS 5351), API 6D, ASME B16.34. |
| Face to Face | ASME B16.10 |
| Testing Std. | API 6D, API-598, EN 12266-1, ASME B16.34, API 607 / 6FA |
| Body Materials | WCB, LCB, CF8, CF8M, CN7M, Duplex etc. |
| Ball Materials | WCB+ENP, CA15, CF8, CF8M, CN7M, Duplex etc. |
| Stem / Trunnion | 17-4PH, UNS S31803 |
| Seat | PTFE / RPTFE / DELRIN / NYLON / PEEK / METAL |
| Metal Seat | 410+Hardened, 316+Stellited. |
| End Connection | Flanged & Butt Weld. |
| End Detail | For FE – ASME B16.5< >For BWE – ASME B16.25 |
